IFC-Based Information Models in openBIM Workflows - Workflow Guide


Course
Quantity
For someone else
Graphisoft Learn
Quantity
For someone else
Purchase for $25 or enter access code

▶︎ Format: PDF
▶︎ Level: advanced
▶︎ Pages: 138

Explore the world of IFC-based modeling with this workflow guide. Delve into IFC schemas and MVDs, understand IFC Translators, and master property mapping in Archicad for robust model integration. Packed with examples, best practices, and troubleshooting tips, this guide is your key to unlocking efficient information modeling.

Use the 'FORWARD' coupon code for free access if you are a FORWARD/SSA client!

Description

This comprehensive guide demystified the intricacies of IFC-based information modeling within the openBIM framework. It offers a thorough exploration of IFC data schemas, delves into Model View Definitions (MVDs), and clarifies the functionalities of IFC Translators. The guide provides a detailed process for mapping IFC properties with Archicad, covering both import and export operations to ensure seamless integration of IFC-based models. Enhanced with practical examples, it aims to foster a deeper understanding of the subject. Furthermore, the guide addresses best practices to optimize workflows and includes strategic troubleshooting techniques for common challenges encountered in information models.
